A pergola all seasons
The bioclimatic pergola Triomphe 3x3m V2 accompanies you to enjoy convivial moments in your garden. Forget about storing your pergola in autumn, this bioclimatic model is suitable for all seasons. The pergola is permanently fixed to the ground. Its adjustable slats allow you to enjoy its shade and coolness in the summer and stay dry the rest of the year. Place it above a garden table, near your pool area, or to shelter your spa.
An aluminum structure
Designed with a quality aluminum structure (frame + legs) with galvanized steel slats, this pergola is a long-term investment. Aluminum is an ideal material for outdoor use, as it does not rust and is resistant to weather conditions and UV rays. This pergola is therefore robust and requires very little maintenance, and it can remain in your garden for many years.
A bit of sun but not too much…
Thanks to a crank, the adjustable slats of the awning are operated. Completely closed, it protects you from the sun’s rays. During the rainiest days, the water is evacuated through the posts by an innovative integrated drainage system. With partial opening, you will benefit from significant ventilation while containing the sun’s light rays. In short, you choose your exposure to the sun.
Additional information:
Although it offers protection against the rain, this pergola is not a completely waterproof shelter.
Your pergola is guaranteed for 2 years + 3 years free from the date of delivery
This new version of the TRIOMPHE pergola is higher than the first and has wider legs. It is compatible with the accessories in the same range (3m awning PGBCRUS3AT and 100cm blind PGBC100PERSAT).
This pergola should be mounted on level ground.
We recommend keeping the slats open in case of snowfall.
Compare our bioclimatic pergolas
Package 1: L 278 x l 26 x h 23.5 cm – 42.94 kg
Package 2: L 303.5 x l 29 x h 17 cm – 32.72 kg
Package 3: L 298.5 x l 32 x h 19 cm – 54.6 kg
Package 4: L 298.5 x l 32 x h 19 cm – 50 kg
Instruction manual
Sun protection: enjoy its freshness in summer
Natural ventilation
Tiltable slats to adjust the light flow
| Type | Louvered pergola |
| Motorised | No |
| Shape | Square |
| Colour | Natural |
| Pantone code | 19-0201 WOOD Imitation |
| Warranty period | 2 years + 3 years free |
| Warranty period | 2 years + 3 years free! (Excluding accessories) |
| Size | 3 x 3 m |
| Surface | 9 m² |
| Length | 3 m |
| Width | 3 m |
| Height to ridge | 2,57 m |
| Entrance height | 2,36 m |
| Height with closed slats | 2,50 m |
| Interior floor area | 8,89 |
| Floor area | 9 m² |
| Post dimensions | L 11 x P 11 x H 250 cm |
| Aluminium thickness | 1,4 / 1,5 mm |
| Slat dimensions | L 294 x D 17 x H 3 cm |
| Slat orientation | 0 to 90 degrees |
| Number of slats | 19 |
| Weight | 158,3 kg |
| Material | Aluminium |
| Frame material | Aluminium |
| Slat material | Galvanised steel |
| Roof material | Aluminium |
| Post material | Aluminium |
| Base material | Aluminium |
| Screw material | Inox |
| Treatment | Powder coating |
| To be fixed to the ground | Yes (anchor kit not included) |
| Crank handle | Yes |
| Wind resistance | 74 km/h |
| Load resistance | 66,4 kg/m² |
| Maximum permissible roof load | 597,6 kg |
| UV resistant | Yes |
| Anti-rust / Corrosion | Yes |
| Water drainage system | By drainage inside the posts |
| Waterproofing | Roof and slats |
| Accessories Included | No |
| Assembly time | 2h / 4 people |
| Number of packages | 4 |
| Use | Outdoor |
| Use | Domestic use only |
| Range | Triomphe |
| Overall external dimensions | L 301 x D 301 x H 257 cm |
Package 1: L 278 x l 26 x h 23.5 cm – 42.94 kg
Package 2: L 303.5 x l 29 x h 17 cm – 32.72 kg
Package 3: L 298.5 x l 32 x h 19 cm – 54.6 kg
Package 4: L 298.5 x l 32 x h 19 cm – 50 kg
Instruction manual
